1.Material: Nylon 66, 94V-2 certificated by UL,brand ASCEND and INVISTA
2.Color: Natural (white), black and colorful.
3.Available size:
Width 2.5mm with length 80mm-200mm
Width 3.6mm with length 100mm-370mm
Width 4.8mm with length 100mm-650mm
Width 7.6mm with length 150mm-550mm
Width 8.8mm with length 400mm-1020mm
1.Usage: Widely used for household,electricity,auto parts,hardware etc.
2.Certification: UL Certification,CE,ROHS,SGS Test Report.
3.Operating Temperature: -40℃ to 85℃.
4.Feature: Acid, Erosion Resistant, Good Insulation and not apt to age.
5.Packing Detail: A.Common Packing: 100Pcs + Polybag + Label + Export Carton. B.Customized Packing: Header card packing, Blister with card packing,or as customized.
6.Delivery time: In 7-30 days after receiving deposit,according to order quantity.
7.Payment Terms: T/T,L/C,Western Union,PayPal.
8.Loading port: NINGBO or SHANGHAI port
9.Tensile strength:18-250LBS
10.Brand: HDS or OEM package
11.Injection Molds: Hot Runner Molds+Central material provided system
12.Injection machines: 12 sets injection machines,large production capacity
13.Export countries to: 50 different countries. Such as Russia,Japan,Vietnam,Argentina,Brazil,Ukraine,Singapore,Thailand,Australia,Turkey, Korea,Malaysia,Korea,Malaysia,Poland and so on. Some of our customers cooperated with our company for more than 10 years,like our customs from Japan,Russia and Turkey.
| Type | L | W(mm) | Max.Bundle Dia.(mm) | Min tensile strength | ||
| Inch | mm | Ibs | kgs | |||
| HDS-3×60 | 2 3/8″ | 60 | 2.5 | 11 | 18 | 8 |
| HDS-3×80 | 3 3/16″ | 80 | 2.5 | 16 | 18 | 8 |
| HDS-3×100 | 4″ | 100 | 2.5 | 22 | 18 | 8 |
| HDS-3×120 | 4 3/4″ | 120 | 2.5 | 30 | 18 | 8 |
| HDS-3×150 | 6″ | 150 | 2.5 | 35 | 18 | 8 |
| HDS-3×160 | 6 1/4″ | 160 | 2.5 | 40 | 18 | 8 |
| HDS-3×200 | 8″ | 200 | 2.5 | 50 | 18 | 8 |
| HDS-4×100 | 4″ | 100 | 3.5 | 22 | 40 | 18 |
| HDS-4×120 | 4 3/4″ | 120 | 3.5 | 30 | 40 | 18 |
| HDS-4×150 | 6″ | 150 | 3.5 | 35 | 40 | 18 |
| HDS-4×180 | 7″ | 180 | 3.5 | 42 | 40 | 18 |
| HDS-4×200 | 8″ | 200 | 3.5 | 50 | 40 | 18 |
| HDS-4×250 | 10″ | 250 | 3.5 | 65 | 40 | 18 |
| HDS-4×300 | 11 5/8″ | 300 | 3.5 | 80 | 40 | 18 |
| HDS-4×370 | 14 1/2″ | 370 | 3.5 | 102 | 40 | 18 |
| HDS-5×100 | 4 | 100 | 4.8 | 22 | 50 | 22 |
| HDS-5×120 | 4 3/4″ | 120 | 4.8 | 30 | 50 | 22 |
| HDS-5×150 | 6″ | 150 | 4.8 | 35 | 50 | 22 |
| HDS-5×180 | 7″ | 180 | 4.8 | 42 | 50 | 22 |
| HDS-5×200 | 8″ | 200 | 4.8 | 50 | 50 | 22 |
| HDS-5×250 | 10″ | 250 | 4.8 | 65 | 50 | 22 |
| HDS-5×300 | 11 5/8″ | 300 | 4.8 | 82 | 50 | 22 |
| HDS-5×350 | 13 3/4″ | 350 | 4.8 | 90 | 50 | 22 |
| HDS-5×380 | 15″ | 380 | 4.8 | 102 | 50 | 22 |
| HDS-5×400 | 15 3/4″ | 400 | 4.8 | 105 | 50 | 22 |
| HDS-5×430 | 17 3/4″ | 430 | 4.8 | 120 | 50 | 22 |
| HDS-5×450 | 17.7″ | 450 | 4.8 | 125 | 50 | 22 |
| HDS-5×500 | 19 11/16″ | 500 | 4.8 | 150 | 50 | 22 |
| HDS-5×530 | 20″ | 530 | 4.8 | 155 | 50 | 22 |
| HDS-8×150 | 6″ | 150 | 7 | 35 | 120 | 55 |
| HDS-8×180 | 7″ | 180 | 7 | 42 | 120 | 55 |
| HDS-8×200 | 8″ | 200 | 7 | 50 | 120 | 55 |
| HDS-8×250 | 10″ | 250 | 7 | 65 | 120 | 55 |
| HDS-8×300 | 11 5/8″ | 300 | 7 | 82 | 120 | 55 |
| HDS-8×350 | 13 3/4″ | 350 | 7 | 90 | 120 | 55 |
| HDS-8×370 | 14 1/2 “ | 370 | 7 | 102 | 120 | 55 |
| HDS-8×400 | 15 3/4″ | 400 | 7 | 105 | 120 | 55 |
| HDS-8×450 | 17 3/4″ | 450 | 7 | 118 | 120 | 55 |
| HDS-8×500 | 19 11/16 “ | 500 | 7 | 150 | 120 | 55 |
| HDS-8×550 | 21 4/5 “ | 550 | 7 | 165 | 120 | 55 |
| HDS-10×400 | 15 3/4″ | 400 | 8.8 | 105 | 175 | 80 |
| HDS-10×450 | 17 3/4″ | 450 | 8.8 | 118 | 175 | 80 |
| HDS-10×500 | 19 11/16 “ | 500 | 8.8 | 150 | 175 | 80 |
| HDS-10×550 | 21 11/16 “ | 550 | 8.8 | 165 | 175 | 80 |
| HDS-10×650 | 25 9/16 “ | 650 | 8.8 | 190 | 175 | 80 |
| HDS-10×760 | 29 1/2 “ | 760 | 8.8 | 220 | 175 | 80 |
| HDS-10×800 | 31 1/2 “ | 800 | 8.8 | 230 | 175 | 80 |
| HDS-10×900 | 36 1/4 “ | 900 | 8.8 | 265 | 200 | 90 |
| HDS-10×1020 | 40 1/6 “ | 1020 | 8.8 | 292 | 200 | 90 |
| HDS-10×1200 | 48″ | 1200 | 8.8 | 345 | 200 | 90 |
| HDS-12×650 | 25 3/5 “ | 650 | 11 | 165 | 250 | 114 |
| HDS-12×760 | 35 1/2 “ | 760 | 11 | 225 | 250 | 114 |
